D-Link DAP-2610 AC1300 Mbps Ethernet Dual-Band Access Point
Brand: D-Link
Category: Network & Accessories
Specification
General
Device Interfaces:
• (1) IEEE 802.11a/b/g/n/ac Wave 2 wireless 1
• (1) Gigabit LAN (supports PoE) Standards
• IEEE 802.11a/b/g/n/ac 1
• IEEE 802.3u/ab
• IEEE 802.3az Energy Efficient Ethernet (EEE)
• IEEE 802.3af Power over Ethernet Antennas
• 2 internal dual-band 3 dBi omni antennas Operating Frequency 3
• 2.4 GHz band: 2.4 GHz to 2.4835 GHz
• 5 GHz band: 5.15 to 5.35 GHz, 5.47 to 5.85 GHz Maximum Output Power
• 23 dBm for 2.4GHz
• 23 dBm for 5GHz
Data Signal Rate
• 2.4 GHz: up to 400 Mbps 1
• 5 GHz: up to 867 Mbps 1
Functionality
Security:
• WPA-Personal
• WPA-Enterprise
• WPA2-Personal
• WPA2-Enterprise
• WEP 64/128-bit encryption
• SSID broadcast disable
• MAC address access control
• Network Access Protection (NAP)
• Internal RADIUS server Network Management:
• Telnet
• Secure Telnet (SSH)
• Web (HTTP)
• Secure Socket Layer (SSL)
• Traffic control
• SNMP v1/v2c/v3
• D-Link Central Wi-Fi Manager
• AP Array
LEDs:
• Power/status
Physical and Environmental
Dimensions:
• 6.69 x 6.69 x 1.1 inches (170 x 170 x 28 mm) Weight
• 0.69 lbs (314 g) without mounting base
• 0.82 lbs (370.6 g) with mounting base Power Supply
• External power adapter: 12V / 1A
• IEEE 802.3af PoE Maximum Power Consumption:
• 12 W
Temperature
• Operating: 32°F to 104°F (0°C to 40°C)
• Storage: -4°F to 149°F (-20°C to 65°C)
Humidity
• Operating: 10% to 90% non-condensing
• Storage: 5% to 95% non-condensing
Meantime Between Failure (MTBF)
• > 30,000 hours
Certifications
• FCC
• IC
• CE
• UL
• Wi-Fi Certified
Warranty
• Limited Lifetime Warranty 4
Ordering Information
• DAP-2610 Wireless AC1300 Wave 2 Dual-Band PoE Access Point
